GIGABYTE B650M AORUS ELITE AX AM5 AMD DDR5 MOTHERBOARD
GIGABYTE B650M AORUS ELITE AX AM5 AMD DDR5 MOTHERBOARD GIGABYTE B650M AORUS ELITE AX AM5 AMD DDR5 MOTHERBOARD - 1 GIGABYTE B650M AORUS ELITE AX AM5 AMD DDR5 MOTHERBOARD - 2 GIGABYTE B650M AORUS ELITE AX AM5 AMD DDR5 MOTHERBOARD - 3 GIGABYTE B650M AORUS ELITE AX AM5 AMD DDR5 MOTHERBOARD - 4 GIGABYTE B650M AORUS ELITE AX AM5 AMD DDR5 MOTHERBOARD - 5

GIGABYTE B650M AORUS ELITE AX AM5 AMD DDR5 MOTHERBOARD

0 Reviews
Stock : In Stock
PID : P0392506251
Brand : Gigabyte
Model : B650M AORUS ELITE AX
Warranty : 3 Years


🎮 FREE LOGITECH F310 WITH PC BUILD

Product Pricing

Discount Price

৳28,800 ৳29,500
+ Available Payment Method

EMI Start From*

৳1,014

PRODUCT SPECIFICATIONS

Processor

Supported CPU AMD Socket AM5, support for: AMD Ryzen™ 7000 Series Processors

Mainboard

Chipset AMD B650
BIOS 1 x 256 Mbit flash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Memory

Memory Support for DDR5 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules

4 x DDR5 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory

Dual channel memory architecture

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules

Storage

Supported Storage 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 5.0* x4/x2 SSD support) (M2A_CPU)

* Actual support may vary by CPU.

1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU)

Chipset:

4 x SATA 6Gb/s connectors

RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices

RAID 0,
RAID 1,
and RAID 10 support for SATA storage devices

Graphics

Graphics 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
* Support for DisplayPort 1.4 version and HDR.

1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version and HDCP 2.3.
** Support native HDMI 2.1 TMDS compatible ports.

Networking & Connectivity

LAN Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
WiFi AMD Wi-Fi 6E RZ616 (MT7922A22M)
(For PCB rev. 1.0)

WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands

Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate

Intel® Wi-Fi 6E AX210 (For PCB rev. 1.1)

WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands

BLUETOOTH 5.3

Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate

(Actual data rate may vary depending on environment and equipment.)
Bluetooth BLUETOOTH 5.2

Audio & Microphone

Audio Realtek® Audio CODEC

High Definition Audio

2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

Support for S/PDIF Out

Ports

Slots 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

Chipset:

1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
Internal I/O Ports 1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

1 x water cooling CPU fan header

3 x system fan headers

1 x system fan/water cooling pump header

2 x addressable LED strip headers

2 x RGB LED strip headers

1 x CPU cooler LED strip/RGB LED strip header

2 x M.2 Socket 3 connectors

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB Type-C® header, with USB 3.2 Gen 2x2 support

1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers

1 x serial port header

1 x THB_U4 add-in card connector

1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)

1 x reset button

1 x reset jumper

1 x Clear CMOS jumper
External I/O Ports 1 x Q-Flash Plus button

2 x SMA antenna connectors (2T2R)

1 x DisplayPort

1 x HDMI port

1 x USB Type-C® port, with USB 3.2 Gen 2 support

2 x USB 3.2 Gen 2 Type-A ports (red)

5 x USB 3.2 Gen 1 ports

4 x USB 2.0/1.1 ports

1 x RJ-45 port

1 x optical S/PDIF Out connector

2 x audio jacks
USB 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support

2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel

CPU + USB 2.0 Hub:

4 x USB 2.0/1.1 ports on the back panel

Chipset:

1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header

3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header)

4 x USB 2.0/1.1 ports available through the internal USB headers

Chipset+USB 3.2 Gen 1 Hub:

4 x USB 3.2 Gen 1 ports on the back pane
HDMI 1 x HDMI port

Special Features

Special Features Support for GIGABYTE Control Center (GCC)

* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

Support for Q-Flash

Support for Q-Flash Plus

Others

Other Features I/O Controller: iTE® I/O Controller Chip

H/W Monitoring

Voltage detection

Temperature detection

Fan speed detection

Water cooling flow rate detection

Fan fail warning

Fan speed control

Operating System

Support for Windows 11 64-bit

Support for Windows 10 64-bit

Physical Specification

Form Factor Micro ATX
Dimension 24.4cm x 24.4cm

Warranty Information

Warranty 3 Years

PRODUCT DESCRIPTION

GIGABYTE B650M AORUS ELITE AX AM5 AMD DDR5 MOTHERBOARD IN BANGLADESH

UNPARALLELED PERFORMANCE

With the fast-moving technology changes, GIGABYTE always follows the latest trends and provides customers with advanced features and the latest technologies. GIGABYTE motherboards are equipped with upgraded power solutions, the latest storage standards, and outstanding connectivity to enable optimized performance for gaming.

Twin Digital VRM Design

To ensure maximum Turbo Boost and overclocking performance of AMD's new generation CPU, GIGABYTE AORUS series motherboard equips the best VRM design ever built with the highest quality components.

PCIe 5.0 Design
Ultra Durable™ SMD PCIe 5.0 x4 M.2 Connector
The first PCIe 5.0 x4 M.2 Slot supports the latest M.2 25110 form factor. It doubles the bandwidth of PCIe 4.0 and ensures that compatible with cutting-edge M.2 SSDs released in the next few years.

OUTSTANDING THERMAL DESIGN
GIGABYTE Motherboards' unparalleled performance is guaranteed by innovative and optimized thermal design to ensure the best CPU, Chipset, SSD stability, and low temperatures under full load application and gaming performance.

1. Fully Covered Thermal Design

    • Real One-piece Build

TMOS is a TRUE single-piece heatsink. Its one-piece design and larger surface drastically improve the cooling performance against competitors' multi-piece designs.


    • 3X Large Surface

The increased surface area is up to 3X larger compared to traditional heatsinks. It improves heat dissipation from the MOSFETs.

    • Multi-Cut Design

Both TMOS & RMOS heatsinks with multiple channels and inlets featured which lead the airflow going through more efficiently and cause a great improvement in heat transfer performance.

2.M.2 Thermal Guard

The M.2 Thermal Guard prevents throttling and bottlenecks from high-speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.

3.8-Layer & 2X Copper PCB

2X COPPER PCBs design effectively lowers the component temperature through its high thermal conductivity and low impedance.

4.6mm Thermal Heatpipe

5.5 W/mK Thermal Pad

CONNECTIVITY

GIGABYTE Motherboards enable the ultimate connection experience with blazing data-transfer speeds through the next generation network, storage, and Wi-Fi connectivity.

802.11ax Wi-Fi 6E

The latest Wireless solution 802.11ax Wi-Fi 6E with new dedicated 6GHz band, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections and speeds up to 2.4Gbps. Moreover, Bluetooth 5 provides 4X range over BT 4.2 and with faster transmission.

First adopter on 2.5GbE LAN onboard

2X Faster than ever

  • Adoption of 2.5G LAN provide up to 2.5 GbE network connectivity, with at least 2X faster transfer speeds compared to general 1GbE networking, perfectly designed for gamers with ultimate online gaming experience.
  • Support Multi-Gig(10/100/1000/2500Mbps) RJ-45 Ethernet

PERSONALIZATION

GIGABYTE motherboards bundle several useful and intuitive software to help users to control every aspect of the motherboard and provide customizable lighting effects with outstanding aesthetics to fit your unique personality.

ULTRA-DURABLE

GIGABYTE Ultra Durable™ design provides product durability and a high-quality manufacturing process. GIGABYTE motherboards use the best components and reinforce every slot to make each of them solid and durable.

PCIe EZ-Latch

Unlock the latch of the PCIe slot easily when removing the graphics card in the PCIe slot.

UEFI BIOS

Friendly User Interface
The EASY MODE shows important hardware information on one page including the CPU clock, Memory, Storage, and Fan.
My Favorites
Add constantly used items to the favorite menu for quick access.
Storage Information
Show all kinds of storage information including SATA, PCI-E, and M.2 interface.
Changelog
List all changes before saving and exiting bios. Quickly review overall settings modification.
Intuitive Load Line Curve
Clearly show each loadline calibration setting in an intuitive curve graph.
Q-Flash Plus
Update the BIOS easily without installing the CPU, memory, and graphics card.
With GIGABYTE Q-Flash Plus, you don't need to install the CPU, memory, and graphics card or enter the BIOS menu to flash the BIOS. Just download and save a new BIOS file (rename to gigabyte.bin) on the USB flash drive, then press the dedicated Q-Flash Plus button and you’re good to go!
