GIGABYTE B840M EAGLE WIFI6 DDR5 AMD AM5 Micro ATX Motherboard
GIGABYTE B840M EAGLE WIFI6 DDR5 AMD AM5 Micro ATX Motherboard GIGABYTE B840M EAGLE WIFI6 DDR5 AMD AM5 Micro ATX Motherboard - 1 GIGABYTE B840M EAGLE WIFI6 DDR5 AMD AM5 Micro ATX Motherboard - 2 GIGABYTE B840M EAGLE WIFI6 DDR5 AMD AM5 Micro ATX Motherboard - 3
Discount Tag

GIGABYTE B840M EAGLE WIFI6 DDR5 AMD AM5 Micro ATX Motherboard

1 Reviews
Stock : In Stock
PID : P0322510005
Brand : Gigabyte
Model : B840M EAGLE WIFI6
Warranty : 3 Years

Chipset: AMD B840

CPU Socket: AMD AM5 Socket

Memory: 2 x DDR5 DIMM

Form Factor: Micro ATX

Product Pricing

Discount Price

৳17,500 ৳19,500
+ Available Payment Method

EMI Start From*

৳616

PRODUCT SPECIFICATIONS

Processor

Supported CPU

AMD Socket AM5, support for:

AMD Ryzen 9000 Series Processors/

AMD Ryzen 8000 Series Processors/

AMD Ryzen 7000 Series Processors

(Go to GIGABYTE's website for the latest CPU support list.)
Chipset

AMD B840

Mainboard

BIOS

1 x 256 Mbit flash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Memory

Memory

Support for DDR5 7600(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5800(O.C) / 5600(O.C) / 5200 / 4800 / 4400 MT/s memory modules.

2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory

Dual-channel memory architecture

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for AMD Extended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules. Please refer to "Memory Support List" on GIGABYTE's website for more information.)

Storage

Supported Storage

1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2580/2280 SSDs:

 AMD Ryzen 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs

AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs

AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs


1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 PCIe 3.0 x2 SSDs

4 x SATA 6Gb/s connectors

RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices

* RAID 5 is only available on AMD Ryzen 9000 Series Processors.



RAID 0, RAID 1, and RAID 10 support for SATA storage devices

Graphics

Graphics

Integrated Graphics Processor with AMD Radeon™ Graphics support:

- 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz

* Support for DisplayPort 1.4 version and HDR.



- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

* Support for HDMI 2.1 version, HDCP 2.3, and HDR.

** Support for native HDMI 2.1 TMDS compatible ports.



(Graphics specifications may vary depending on CPU support.)

Networking & Connectivity

LAN

Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
WiFi

Realtek Wi-Fi 6 RTL8851BE

- WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands

- Support for 11ax 80MHz wireless standard
Bluetooth

- BLUETOOTH 5.3

Audio & Microphone

Audio

Realtek Audio CODEC

High Definition Audio

2/4/5.1/7.1-channel

* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

Ports

Slots

Expansion Slots:

1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:

AMD Ryzen 9000/7000 Series Processors support PCIe 4.0 x16 mode

AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode

AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode

Chipset:

- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)
Internal I/O Ports

1x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

1 x CPU fan/water cooling pump header

1 x system fan header

1 x system fan/water cooling pump header

2 x addressable RGB Gen2 LED strip headers

1 x RGB LED strip header

2 x M.2 Socket 3 connectors

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB Type-C header, with USB 3.2 Gen 1 support

1 x USB 3.2 Gen 1 header

2 x USB 2.0/1.1 headers

1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)

1 x reset jumper

1 x Clear CMOS jumper
External I/O Ports

1 x PS/2 keyboard/mouse port

4 x USB 2.0/1.1 ports

1 x DisplayPort (Note)

1 x HDMI port (Note)

1 x Q-Flash Plus button

2 x USB 3.2 Gen 1 ports

1 x RJ-45 port

2 x SMA antenna connectors (2T2R)

3 x audio jacks


(Note) Actual support may vary by CPU.
USB

CPU:

- 2 x USB 3.2 Gen 1 ports on the back panel

CPU+USB 2.0 Hub:

- 4 x USB 2.0/1.1 ports on the back panel

Chipset:

- 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header

- 2 x USB 3.2 Gen 1 ports available through the internal USB headers

- 4 x USB 2.0/1.1 ports available through the internal USB headers

Software

Bundled Software

Norton Internet Security (OEM version)

LAN bandwidth management software
Operating System

Support for Windows 11 64-bit

Support for Windows 10 64-bit

Special Features

Special Features

Support for GIGABYTE Control Center (GCC)

* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on the motherboard specifications.


Support for Q-Flash

Support for Q-Flash Plus

Support for Smart Backup

Others

Controller

I/O Controller: iTE I/O Controller Chip
Other Features

H/W Monitoring

Voltage detection

Temperature detection

Fan speed detection

Water cooling flow rate detection

Fan fail warning

Fan speed control

* Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

Physical Specification

Form Factor

Micro ATX Form Factor; 24.4cm x 24.4cm

Warranty Information

Warranty 3 Years

PRODUCT DESCRIPTION

GIGABYTE B840M EAGLE WIFI6 Micro ATX Motherboard Price in Bangladesh

GIGABYTE B840M EAGLE WIFI6 DDR5 AMD AM5 Micro ATX Motherboard delivers powerful performance and next-generation features for gaming, content creation, and productivity. Designed for AMD Ryzen 9000, 8000, and 7000 series processors, this board is built on the AMD B840 chipset, ensuring stable and high-speed operation. With dual DDR5 DIMM slots supporting up to 128GB of RAM and speeds reaching 7600MHz (O.C.), it allows users to push performance to new limits. This motherboard supports dual-display output via HDMI 2.1 and DisplayPort 1.4, both offering 4K resolution with HDR, ensuring stunning visuals for gaming or design work. It also comes equipped with Realtek 2.5GbE LAN and Wi-Fi 6 with Bluetooth 5.3, delivering ultra-fast and reliable network connectivity.

Storage flexibility is provided by two M.2 PCIe slots and four SATA 6Gb/s ports, supporting both PCIe 4.0 and 3.0 NVMe SSDs, enabling lightning-fast data transfer and RAID configuration for advanced setups. For expandability, the PCIe x16 slot supports up to PCIe 4.0 bandwidth, offering compatibility with modern GPUs. The integrated Realtek HD Audio codec provides rich, immersive 7.1-channel sound. Additionally, users can customize system lighting through RGB and addressable Gen2 LED headers, enhancing both performance and aesthetics.

The GIGABYTE B840M EAGLE also includes convenient features such as Q-Flash Plus, Smart Backup, and GIGABYTE Control Center (GCC) for seamless BIOS updates and system management. With a Micro ATX form factor (24.4cm x 24.4cm), it’s ideal for compact builds without sacrificing power. Whether you’re building a gaming PC or a workstation, this motherboard ensures speed, stability, and future-ready performance — a perfect balance of innovation and reliability at a competitive price in Bangladesh. The GIGABYTE B840M DS3H AMD motherboard delivers reliable power delivery, DDR5 memory support, and excellent compatibility for Ryzen processors. A great choice for budget and mid-range PC builds, offering strong performance at an affordable motherboard price in BD.

Buy the Best GIGABYTE B840M EAGLE WIFI6 Motherboard in Bangladesh from Tech Land BD

Buy the GIGABYTE B840M EAGLE WIFI6 DDR5 AMD AM5 Micro ATX Motherboard from Tech Land BD, the most trusted source for computer components in Bangladesh. Known for quality and authenticity, Tech Land BD offers the latest AMD motherboards at competitive prices. This model supports DDR5 RAM, PCIe 4.0, Wi-Fi 6, and 2.5GbE LAN, making it ideal for gamers and professionals who demand speed and reliability. Tech Land BD ensures genuine products with full warranty, expert customer support, and fast nationwide delivery, helping you build your perfect PC with confidence.

Which processors are compatible with the GIGABYTE B840M EAGLE motherboard?

This motherboard supports AMD Ryzen 9000, 8000, and 7000 Series Processors with the AM5 socket.

Does it support DDR5 RAM and overclocking?

Yes, it supports DDR5 memory up to 128GB and up to 7600MHz (O.C.), allowing high-speed overclocking with AMD EXPO or XMP profiles.

What connectivity options does this motherboard offer?

It features Wi-Fi 6, Bluetooth 5.3, 2.5GbE LAN, PCIe 4.0 support, multiple USB ports, and dual-display output via HDMI and DisplayPort.

CUSTOMER REVIEWS

Overall Rating

5 out of 5 stars
1
Total Reviews

Login to write a review.

5 star
1
4 star
0
3 star
0
2 star
0
1 star
0
kalam sikdar

Works fine, but it’s a basic board. No CPU overclocking and limited advanced features compared to B650/B850 boards.

10 April, 2025

What is the GIGABYTE B840M EAGLE WIFI6 DDR5 AMD AM5 Micro ATX Motherboard Price in Bangladesh 2026 ?

The Gigabyte B840M EAGLE WIFI6 Price in BD is 17,500৳ . This GIGABYTE B840M EAGLE WIFI6 DDR5 AMD AM5 Micro ATX Motherboard Manufacturing by Gigabyte Comes With 3 Years Warranty & Based on 1 reviews. Tech Land BD Offers you Gigabyte B840M EAGLE WIFI6 by 17,500৳ and its regular price is 19,500৳ Which is also In Stock Now at our Showroom. Follow us on Facebook For Regular updates & Offer. Subscribe Our YouTube Channel for Product Reviews.
