Product Information

Save: ৳600
Gigabyte B860M EAGLE PLUS WIFI6E DDR5 Micro ATX Intel Motherboard
Gigabyte B860M EAGLE PLUS WIFI6E DDR5 Micro ATX Intel Motherboard Gigabyte B860M EAGLE PLUS WIFI6E DDR5 Micro ATX Intel Motherboard - 1 Gigabyte B860M EAGLE PLUS WIFI6E DDR5 Micro ATX Intel Motherboard - 2 Gigabyte B860M EAGLE PLUS WIFI6E DDR5 Micro ATX Intel Motherboard - 3

Gigabyte B860M EAGLE PLUS WIFI6E DDR5 Micro ATX Intel Motherboard

2 Reviews
Stock : In Stock
PID : P0322508019
Brand : Gigabyte
Model : B860M EAGLE PLUS WIFI6E
Warranty : 3 Years
  • Form Factor - Micro ATX
  • Operating System - Windows 11 64-bit
  • CPU - LGA1851 Intel Core Ultra Processor
  • Chipset - Intel  B860 Express Chipset

⌨️ PC BUILD + FREE KL-139 KEYBOARD

Product Pricing

Discount Price

৳30,900 ৳31,500
+ Available Payment Method

EMI Start From*

৳1,088

PRODUCT SPECIFICATIONS

Processor

Supported CPU

LGA1851 socket: Support for Intel  Core Ultra Processors

(Go to GIGABYTE's website for the latest CPU support list.)

L3 cache varies with CPU
Chipset

Intel B860 Express Chipset

Mainboard

BIOS

1 x 256 Mbit flash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Memory

Memory

Support for DDR5 9066(O.C)/8800(O.C) /8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) /6400/5600 MT/s memory modules

4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory

Dual channel memory architecture

Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Profile (XMP) memory modules

Support CUDIMM memory module

Storage

Supported Storage

CPU:

- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 5.0 x4/x2 SSD support)(M2A_CPU)

Chipset:

- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)(M2N_SB)

- 4 x SATA 6Gb/s connectors

RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices

Graphics

Graphics

Integrated Graphics Processor-Intel HD Graphics support:

- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

* Support for HDMI 2.1 version and HDCP 2.3.


- 2 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz

* Support for DisplayPort 2.1 version.

Networking & Connectivity

LAN

Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
WiFi

Intel Wi-Fi 6E AX211 (PCB rev. 1.0/2.0)

- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz
carrier frequency band

Realtek Wi-Fi 6E RTL8852CE (PCB rev. 1.1/2.1)

- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz
carrier frequency bands
Bluetooth

 BLUETOOTH 5.3

- Support for 11ax 160MHz wireless standard

Audio & Microphone

Audio

Realtek Audio CODEC

High Definition Audio

2/4/5.1/7.1-channel

* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio,
access the audio software for audio settings.

Ports

Slots

CPU:

- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)

* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.


Chipset:

- 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x1 (PCIEX1_2/3)
Internal I/O Ports

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

1 x CPU fan/water cooling pump header

1 x system fan header

1 x system fan/water cooling pump header

3 x addressable RGB Gen2 LED strip headers

1 x RGB LED strip header

2 x M.2 Socket 3 connectors

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB Type-C header, with USB 3.2 Gen 1 support

1 x USB 3.2 Gen 1 header

2 x USB 2.0/1.1 headers

1 x Trusted Platform Module header (For the GC-TPM2.0 SPI V2 module only)

1 x Q-Flash Plus button

1 x reset jumper

1 x Clear CMOS jumper
External I/O Ports

1 x PS/2 keyboard/mouse port

1 x HDMI port*

2 x DisplayPorts*

1 x USB 3.2 Gen 2 Type-A port (red)

2 x USB 3.2 Gen 1 ports

3 x USB 2.0/1.1 ports

2 x antenna connectors (2T2R)

1 x RJ-45 port

3 x audio jacks


* Actual support may vary by CPU.
USB

Chipset:

- 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header

- 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel

- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)

- 3 x USB 2.0/1.1 ports on the back panel

Chipset+USB 2.0 Hub:

- 4 x USB 2.0/1.1 ports available through the internal USB headers

Software

Bundled Software

Norton Internet Security (OEM version)

LAN bandwidth management software
Operating System

Support for Windows 11 64-bit

Support for Windows 10 64-bit

Special Features

Special Features

Support for GIGABYTE Control Center (GCC)

Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup

Others

Controller

iTE I/O Controller Chip
Other Features

Voltage detection

Temperature detection

Fan speed detection

Water cooling flow rate detection

Fan fail warning

Fan speed control

Physical Specification

Form Factor

Micro ATX Form Factor; 24.4cm x 24.4cm

Warranty Information

Warranty

3-Years

PRODUCT DESCRIPTION

Gigabyte B860M EAGLE PLUS WIFI6E DDR5 Micro ATX Motherboard Price in Bangladesh

Gigabyte B860M EAGLE PLUS WIFI6E DDR5 Micro ATX Motherboard is a feature-rich board designed to deliver next-generation performance for Intel’s latest Core Ultra processors with the LGA1851 socket. Powered by the Intel B860 Express chipset, this motherboard supports DDR5 memory up to 9066 MT/s (O.C.), enabling ultra-fast speeds and superior multitasking performance. With four DIMM slots supporting up to 256GB RAM, it offers excellent scalability for gaming, productivity, and creative workloads. For graphics, it comes with integrated Intel HD Graphics support, offering one HDMI 2.1 port (4K@60Hz) and dual DisplayPort 2.1 outputs (4K@144Hz), supporting up to triple displays simultaneously.

On the connectivity side, it includes Realtek 2.5GbE LAN and Intel Wi-Fi 6E AX211 / Realtek Wi-Fi 6E with Bluetooth 5.3, ensuring fast, stable, and modern networking. Storage options are robust with two M.2 slots (PCIe 5.0 and PCIe 4.0) and four SATA 6Gb/s connectors, supporting RAID 0/1/5/10 for data security and speed. Expansion is supported by a PCIe 5.0 x16 slot for graphics cards and two PCIe 4.0 slots for additional cards. The motherboard also provides multiple USB options, including USB 3.2 Gen 2, USB 3.2 Gen 1, USB Type-C, and legacy USB 2.0 ports.

The Gigabyte B860M EAGLE PLUS also comes with RGB Fusion headers (ARGB Gen2 & RGB LED) for customization, Q-Flash Plus for BIOS updates without CPU, and premium Realtek Audio CODEC with up to 7.1-channel support for immersive sound. With its Micro ATX form factor, this board is ideal for compact, powerful builds, making it a perfect choice for gamers, content creators, and performance enthusiasts in Bangladesh. Order now from Tech Land BD at the best price and enjoy a 1-year warranty with reliable after-sales service.


Does the Gigabyte B860M EAGLE PLUS support DDR4 RAM?

No, this motherboard only supports DDR5 memory up to 9066 MT/s (overclocked).

Can I install two NVMe SSDs on this motherboard?

Yes, it has two M.2 slots – one PCIe 5.0 and one PCIe 4.0 – allowing dual NVMe SSD setup.

Does it have built-in Wi-Fi and Bluetooth?

Yes, it features Wi-Fi 6E and Bluetooth 5.3 for seamless wireless connectivity.

CUSTOMER REVIEWS

Overall Rating

4 out of 5 stars
2
Total Reviews

Login to write a review.

5 star
0
4 star
2
3 star
0
2 star
0
1 star
0
Engr. Jubayer Ahmed

i got one working fine , i want to buy another one

07 July, 2026

A K Adi onny

Best discount on this motherboard thanks

30 June, 2026

What is the Gigabyte B860M EAGLE PLUS WIFI6E DDR5 Micro ATX Intel Motherboard Price in Bangladesh 2026 ?

The Gigabyte B860M EAGLE PLUS WIFI6E Price in BD is 30,900৳ . This Gigabyte B860M EAGLE PLUS WIFI6E DDR5 Micro ATX Intel Motherboard Manufacturing by Gigabyte Comes With 3 Years Warranty & Based on 0 reviews. Tech Land BD Offers you Gigabyte B860M EAGLE PLUS WIFI6E by 30,900৳ and its regular price is 31,500৳ Which is also In Stock Now at our Showroom. Follow us on Facebook For Regular updates & Offer. Subscribe Our YouTube Channel for Product Reviews.
