GIGABYTE B860M GAMING WIFI6 Intel B860 DDR5 Micro ATX Motherboard
GIGABYTE B860M GAMING WIFI6 Intel B860 DDR5 Micro ATX Motherboard GIGABYTE B860M GAMING WIFI6 Intel B860 DDR5 Micro ATX Motherboard - 1 GIGABYTE B860M GAMING WIFI6 Intel B860 DDR5 Micro ATX Motherboard - 2 GIGABYTE B860M GAMING WIFI6 Intel B860 DDR5 Micro ATX Motherboard - 3

GIGABYTE B860M GAMING WIFI6 Intel B860 DDR5 Micro ATX Motherboard

3 Reviews
Stock : In Stock
PID : P0392506494
Brand : Gigabyte
Model : B860M GAMING WIFI6
Warranty : 3-Years
  • CPU - LGA1851 socket
  • Chipset - Intel B860 Express Chipset
  • Operating System - Support for Windows 11 64-bit / 10 64-bit
  • Form Factor - Micro ATX Form Factor; 24.4cm x 22.5cm

    • 🎮 FREE LOGITECH F310 WITH PC BUILD

    Product Pricing

    Discount Price

    ৳25,200 ৳26,000
    + Available Payment Method

    EMI Start From*

    ৳887

    PRODUCT SPECIFICATIONS

    Processor

    CPU Socket LGA1851 socket: Support for Intel Core Ultra Processors

    (Go to GIGABYTE's website for the latest CPU support list.)

    L3 cache varies with CPU

    Mainboard

    Chipset Intel B860 Express Chipset
    BIOS 1 x 256 Mbit flash

    Use of licensed AMI UEFI BIOS

    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

    Memory

    Memory Support for DDR5 9066(O.C)/8800(O.C) /8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) /
    8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) /
    7000(O.C.) / 6800(O.C.) / 6600(O.C.) /6400/5600 MT/s memory modules

    2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system
    memory
    Dual channel memory architecture

    Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

    Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

    Support for Extreme Memory Profile (XMP) memory modules

    (The CPU and memory configuration may affect the supported memory types, data rate
    (speed), and number of DRAM modules, please refer to "Memory Support List" on
    GIGABYTE's website for more information.)

    Graphics

    Graphics Integrated Graphics Processor-Intel HD Graphics support:

    - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

    * Support for HDMI 2.1 version and HDCP 2.3.





    - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz

    * Support for DisplayPort 2.1 version.





    (Graphics specifications may vary depending on CPU support.)

    Networking & Connectivity

    LAN Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
    Wireless Realtek Wi-Fi 6 RTL8851BE

    - WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands

    - BLUETOOTH 5.3

    - Support for 11ax 80MHz wireless standard

    (Actual data rate may vary depending on environment and equipment.)

    Audio & Microphone

    Audio Realtek Audio CODEC

    High Definition Audio

    2/4/5.1/7.1-channel

    * You can change the functionality of an audio jack using the audio software. To
    configure 7.1-channel audio, access the audio software for audio settings.



    Support for S/PDIF Out

    Ports

    Interface CPU:

    - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU)

    Chipset:

    - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)

    - 4 x SATA 6Gb/s connectors

    RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
    Internal I/O Ports 1 x 24-pin ATX main power connector

    1 x 8-pin ATX 12V power connector

    1 x CPU fan header

    1 x CPU fan/water cooling pump header

    1 x system fan header

    1 x system fan/water cooling pump header

    3 x addressable RGB Gen2 LED strip headers

    2 x M.2 Socket 3 connectors


    4 x SATA 6Gb/s connectors

    1 x front panel header

    1 x front panel audio header

    1 x S/PDIF Out header

    1 x USB Type-C header, with USB 3.2 Gen 1 support

    1 x USB 3.2 Gen 1 header

    2 x USB 2.0/1.1 headers

    1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI
    2.0/GC-TPM2.0 SPI V2 module only)

    1 x serial port header

    1 x Q-Flash Plus button

    1 x reset jumper

    1 x Clear CMOS jumper



    Back Panel Connectors

    1 x PS/2 keyboard/mouse port

    1 x HDMI port (Note)

    1 x DisplayPort (Note)

    3 x USB 3.2 Gen 1 ports

    3 x USB 2.0/1.1 ports

    2 x antenna connectors (2T2R)

    1 x RJ-45 port

    3 x audio jacks



    (Note) Actual support may vary by CPU.
    USB Chipset:

    - 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB
    header

    - 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the
    internal USB header)

    - 3 x USB 2.0/1.1 ports on the back panel

    Chipset+USB 2.0 Hub:

    - 4 x USB 2.0/1.1 ports available through the internal USB headers

    Software

    Bundled Software Norton Internet Security (OEM version)

    LAN bandwidth management software
    Operating System Support for Windows 11 64-bit

    Support for Windows 10 64-bit

    * The Intel NPU driver is only supported on Windows 11

    Special Features

    Features Support for GIGABYTE Control Center (GCC)

    * Available applications in GCC may vary by motherboard model. Supported functions of
    each application may also vary depending on motherboard specifications.




    Support for Q-Flash

    Support for Q-Flash Plus

    Support for Smart Backup

    Others

    Controller iTE I/O Controller Chip
    Other Features H/W Monitoring

    Voltage detection

    Temperature detection

    Fan speed detection

    Water cooling flow rate detection

    Fan fail warning

    Fan speed control

    * Whether the fan (pump) speed control function is supported will depend on the fan
    (pump) you install.

    Physical Specification

    Expansion Slots CPU:

    - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)

    * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one
    graphics card is to be installed, be sure to install it in the PCIEX16 slot.





    Chipset:

    - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
    Form Factor Micro ATX Form Factor; 24.4cm x 22.5cm

    Technical Info

    Brand GIGABYTE
    Model B860M GAMING WIFI6

    Warranty Information

    Warranty 3-Years

    PRODUCT DESCRIPTION

    GIGABYTE B860M GAMING WIFI6 Intel B860 DDR5 Micro ATX Motherboard in Bangladesh

    GIGABYTE B860M GAMING WIFI6 is a high-performance Micro ATX motherboard designed to support Intel Core Ultra Processors with the LGA1851 socket. Featuring the Intel B860 Express chipset, this motherboard provides robust performance with DDR5 memory support up to 9066 MT/s (O.C) across two DIMM slots, offering a maximum capacity of 128GB. It includes PCIe 5.0 x16 and PCIe 4.0 x4 slots for enhanced graphics and expansion capabilities, ensuring seamless performance for gaming and multitasking. The onboard graphics support HDMI 2.1 and DisplayPort 2.1 for high-resolution, multi-display setups. Networking and connectivity are enhanced with Realtek 2.5GbE LAN and Wi-Fi 6 with Bluetooth 5.3, ensuring fast and stable connections.

    Storage options include dual M.2 slots (PCIe 5.0 & PCIe 4.0) and four SATA 6Gb/s ports, supporting RAID 0, 1, 5, and 10 for flexible storage solutions. The USB connectivity is extensive, featuring USB 3.2 Gen 1 and USB 2.0 ports, including a USB Type-C header. Additionally, the board comes with high-definition Realtek audio, multiple RGB headers, and GIGABYTE Control Centre (GCC) for system customisation. With support for Windows 11 and Q-Flash Plus for BIOS updates, this motherboard is an ideal choice for gamers and power users. Get the GIGABYTE B860M GAMING WIFI6 from Tech Land BD today and experience superior performance with next-gen features.


    What processors are compatible with the GIGABYTE B860M GAMING WIFI6 motherboard?

    The motherboard supports Intel Core Ultra Processors on the LGA1851 socket. For a complete compatibility list, please check GIGABYTE’s official website.

    Does this motherboard support Wi-Fi and Bluetooth?

    Yes, it features Realtek Wi-Fi 6 and Bluetooth 5.3, ensuring high-speed wireless connectivity and seamless peripheral pairing.

    How many RAM slots does this motherboard have, and what is the maximum memory capacity?

    It has two DDR5 DIMM slots, supporting up to 128GB of memory with speeds up to 9066 MT/s (O.C.).
