ASUS B650M-AYW WIFI AMD Ryzen AM5 DDR5 Micro-ATX Motherboard
ASUS B650M-AYW WIFI AMD Ryzen AM5 DDR5 Micro-ATX Motherboard ASUS B650M-AYW WIFI AMD Ryzen AM5 DDR5 Micro-ATX Motherboard - 1 ASUS B650M-AYW WIFI AMD Ryzen AM5 DDR5 Micro-ATX Motherboard - 2 ASUS B650M-AYW WIFI AMD Ryzen AM5 DDR5 Micro-ATX Motherboard - 3
Discount Tag

ASUS B650M-AYW WIFI AMD Ryzen AM5 DDR5 Micro-ATX Motherboard

0 Reviews
Stock : In Stock
PID : P0122506908
Brand : Asus
Model : B650M-AYW WIFI
Warranty : 3-Years
  • Chipset: AMD B650 Chipset
  • Socket: AMD Socket AM5
  • Memory: 2 x DIMM slots, max. 96GB, DDR5
  • Storage: Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports

    • Product Pricing

    Night Offer Price 00:00:00

    ৳19,300 ৳21,000
    + Available Payment Method

    EMI Start From*

    ৳680

    PRODUCT SPECIFICATIONS

    Processor

    CPU Socket AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors

    Mainboard

    Chipset AMD B650 Chipset

    Memory

    Memory 2 x DIMM slots, max. 96GB,

    DDR5 Supports up to 8000+MT/s (OC) with Ryzen 9000 & 8000 & 7000 Series Processors,

    ECC and Non-ECC Un-buffered DIMM*

    Dual Channel Memory Architecture

    Supports AMD Extended Profiles for Overclocking (EXPO)

    OptiMem II

    * Supported memory types, data rate (speed), and number of DRAM

    modules vary depending on the CPU and memory configuration.

    For more information, please refer to the CPU/Memory Support list under

    the Support tab of the product information site or visit https://www.asus.com/support/download-center/

    * Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function.

    Storage

    Storage Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*

    AMD Ryzen 9000 & 7000 Series Desktop Processors

    M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)

    M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)

    AMD Ryzen 8000 Series Desktop Processors

    M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)

    M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4/x2 mode)**

    AMD B650 Chipset

    4 x SATA 6Gb/s ports

    * AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/10 and SATA RAID 0/1/10.

    ** Specifications vary by CPU type.

    Graphics

    Graphics 1 x HDMI port**

    * Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.

    ** Supports 4K@60Hz as specified in HDMI 2.1.

    Networking & Connectivity

    Ethernet 1 x Realtek 2.5Gb Ethernet

    Audio & Microphone

    Audio Realtek 7.1 Surround Sound High Definition Audio CODEC*

    - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking

    - Supports up to 24-Bit/192 kHz playback



    Audio Features

    - Audio Shielding

    - Premium audio capacitors

    - Dedicated audio PCB layers

    * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

    Ports

    I/O Port Back Panel I/O Ports:

    2 x USB 10Gbps ports (2 x Type-A)

    2 x USB 5Gbps ports (2 x Type-A)

    4 x USB 2.0 ports (4 x Type-A)

    1 x HDMI port

    1 x Wi-Fi Module

    1 x Realtek 2.5Gb Ethernet port

    3 x Audio jacks



    Internal I/O Connectors:

    Fan and Cooling-related

    1 x 4-pin CPU Fan header

    2 x 4-pin Chassis Fan headers



    Power related

    1 x 24-pin Main Power connector

    1 x 8-pin +12V Power connector


    Storage related

    2 x M.2 slots (Key M)

    4 x SATA 6Gb/s ports



    USB

    1 x USB 5Gbps connector (supports USB Type-C)

    1 x USB 5Gbps header supports 2 additional USB 5Gbps ports

    2 x USB 2.0 headers support 4 additional USB 2.0 ports



    Miscellaneous

    3 x Addressable Gen 2 headers

    1 x Clear CMOS header

    1 x COM Port header

    1 x Front Panel Audio header (F_AUDIO)

    1 x S/PDIF Out header

    1 x 10-1 pin System Panel header
    USB Rear USB (Total 8 ports)

    2 x USB 10Gbps ports (2 x Type-A)

    2 x USB 5Gbps ports (2 x Type-A)

    4 x USB 2.0 ports (4 x Type-A)

    Front USB (Total 7 ports)

    1 x USB 5Gbps connector (supports USB Type-C)

    1 x USB 5Gbps header supports 2 additional USB 5Gbps ports

    2 x USB 2.0 headers support 4 additional USB 2.0 ports

    Software

    Operating System Windows 11, Windows 10 64-bit
    Software Features ASUS Exclusive Software

    Armoury Crate

    - Aura Creator

    - Aura Sync

    - Fan Xpert 2+

    - Power Saving

    - Two-Way AI Noise Cancellation



    AI Suite 3

    - TurboV EVO

    - DIGI+ VRM

    - PC Cleaner

    ASUS CPU-Z


    Norton 360 Deluxe (60 Days Free Trial)

    WinRAR (40 Days Free Trial)

    UEFI BIOS

    ASUS EZ DIY

    - ASUS CrashFree BIOS 3

    - ASUS EZ Flash 3

    - ASUS UEFI BIOS EZ Mode

    Special Features

    Special Features ASUS 5X PROTECTION III

    - DIGI+ VRM

    - LANGuard

    - Overvoltage Protection

    - Safeslot Core+

    - Stainless-Steel Back I/O



    ASUS Q-Design

    - M.2 Q-Latch

    - Q-DIMM

    - Q-LED Core

    - Q-Slot



    ASUS Thermal Solution

    - M.2 heatsink

    - VRM heatsink design



    Aura Sync

    - Addressable Gen 2 headers

    Others

    Accessories Cables

    2 x SATA 6Gb/s cables



    Miscellaneous

    1 x ASUS Wi-Fi moving antenna

    1 x I/O Shield

    1 x M.2 Rubber Package

    1 x Screw Package for M.2 SSD



    Documentation

    1 x Quick start guide
    Other Features Manageability: WOL by PME, PXE

    Physical Specification

    Color Black & White
    Expansion Slots AMD Ryzen 9000 & 7000 Series Desktop Processors*

    1 x PCIe 4.0 x16 slot (supports x16 mode)

    AMD Ryzen 8000 Series Desktop Processors

    1 x PCIe 4.0 x16 slot (supports x8/x4 mode)**


    AMD B650 Chipset

    1 x PCIe 4.0 x16 slot (supports x4 mode)

    * Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/).

    ** Specifications vary by CPU type.

    - To ensure compatibility of the device installed, please refer to

    https://www.asus.com/support/download-center/ for the list of supported peripherals.
    Form Factor Micro-ATX Form Factor

    9.6 inch x 8.7 inch ( 24.4 cm x 22.1 cm )

    Technical Info

    Brand Asus
    Model B650M-AYW WIFI

    Warranty Information

    Warranty 3-Year Replacement Warranty

    PRODUCT DESCRIPTION

    ASUS B650M-AYW WIFI AMD Ryzen AM5 DDR5 Micro-ATX Motherboard in Bangladesh

    ASUS B650M-AYW WIFI is a high-performance micro-ATX motherboard designed for AMD Ryzen 9000, 8000, and 7000 series processors, featuring the AMD B650 chipset and DDR5 memory support for ultra-fast speeds up to 8000+MT/s (OC). With 2 DIMM slots supporting up to 96GB of RAM, this motherboard ensures smooth multitasking and gaming performance. It includes PCIe 4.0 and 5.0 support, offering lightning-fast data transfer speeds for NVMe SSDs and high-end GPUs. The dual M.2 slots (PCIe 5.0 x4 & PCIe 4.0 x4) provide ample storage options, while 4 SATA 6Gb/s ports cater to additional HDD/SSD needs. For seamless connectivity, it features 2.5 Gb Ethernet, Wi-Fi, Bluetooth, USB 10 Gbps (Type-A & Type-C), and HDMI 2.1 (4K@60Hz). The Realtek 7.1 Surround Sound audio with premium capacitors ensures immersive sound quality. Built with ASUS 5X Protection III, including DIGI+ VRM, LANGuard, and overvoltage protection, this motherboard guarantees durability and stability. Additional features like Aura Sync RGB lighting, M.2 heatsinks, and Q-Latch for easy installation make it a top choice for gamers and PC builders. Available at Tech Land BD, this motherboard is perfect for high-end gaming, content creation, and productivity tasks.


    FAQs:

    Does the ASUS B650M-AYW WIFI support AMD Ryzen 7000 series processors?

    Yes, it supports AMD Ryzen 9000, 8000, and 7000 series processors with the AM5 socket. Always check ASUS’s official CPU support list for compatibility.


    What type of RAM does this motherboard support?

    It supports DDR5 memory with speeds up to 8000+MT/s (overclocked) and features EXPO (AMD’s memory overclocking technology) for enhanced performance.


    Does this motherboard include Wi-Fi and Bluetooth?

    Yes, it comes with built-in Wi-Fi and Bluetooth for wireless connectivity, along with a 2.5 Gb Ethernet port for high-speed wired networking.



    CUSTOMER REVIEWS

    Overall Rating

    0 out of 5 stars
    0
    Total Reviews

    Login to write a review.

    5 star
    0
    4 star
    0
    3 star
    0
    2 star
    0
    1 star
    0

    No reviews yet

    Be the first to share your thoughts about this product.

    What is the ASUS B650M-AYW WIFI AMD Ryzen AM5 DDR5 Micro-ATX Motherboard Price in Bangladesh 2026 ?

    The Asus B650M-AYW WIFI Price in BD is 19,900৳ . This ASUS B650M-AYW WIFI AMD Ryzen AM5 DDR5 Micro-ATX Motherboard Manufacturing by Asus Comes With 3-Years Warranty & Based on 0 reviews. Tech Land BD Offers you Asus B650M-AYW WIFI by 19,900৳ and its regular price is 21,000৳ Which is also In Stock Now at our Showroom. Follow us on Facebook For Regular updates & Offer. Subscribe Our YouTube Channel for Product Reviews.
